Displacer Type level Switch

Name: Displacer Type level Switch
Brand: Flow And Control System Pvt. Ltd.
Price: 5500.0 INR
Availability: InStock

Price 5500.0 INR/ Set

Get a Price/Quote

MOQ : 1 Set

Displacer Type level Switch Specification

Features
Field adjustable set point, robust wetted parts, explosion-proof version available

Port Size
1 BSP (Standard), others on request

Automation Grade
Automatic switching

Humidity
Up to 95% RH (Non-condensing)

Frequency
50/60 Hz (if electric switching)

Measuring Range
120 mm to 2000 mm (depends on displacer length)

Usage
TO CONTROL LIQUID LEVEL IN TANK

Accuracy
10 mm (subject to installation and liquid type)

Material
Metal

Max Height
2000 mm displacer rod (Depends on application)

Display Type
No built-in display

Interface Type
Electrical terminal connection

Temperature
-20C to 80C (standard); High temp versions available

Mounting Type
Top/Side/BSP Threaded

Product Type
Displacer level Switch

Operating Voltage
230V AC / 24V DC

Resolution
Level switch (not continuous), discrete output

Color
Silver

Power Supply
230V AC / 24V DC (as per model)

Response Time
Instantaneous mechanical operation

Application
Liquid Level Detection in tanks & vessels

Capacity
Up to 15 kg/cm2 (varies by version)

Machine Weight
Approx. 2.5 kg

Control Mode
On/Off, optional SPDT/DPDT

Output
SPST / SPDT / DPDT

Ingress Protection
IP65 (standard), optional IP67/IP68

Switch Type
Micro-switch / proximity (optional)

Minimum Density
0.6 kg/dm3 (varies for special designs)

Process Connection
Flanged/Threaded as required

Equipment Type
Displacer Type Level Switch

Ambient Temperature
-10C to 60C

Explosion Proof
Available as per IS/IEC standards

Material of Construction
SS304 / SS316 wetted parts, engineering plastic or aluminum enclosure

Displacer Material
SS316/SS304/PTFE coated (as per process requirement)

Contact Rating
5A @ 240V AC, 0.25A @ 220V DC

Enclosure Material
Cast aluminum/polycarbonate (as per model)

Cable Entry
3/4" NPT (standard), other options available

Medium Compatibility
Water, oils, solvents, chemicals (depends on MOC)

Displacer Type level Switch Trade Information

Minimum Order Quantity
1 Set

Delivery Time
1-2 Week

About Displacer Type level Switch

Buy the commanding Displacer Type Level Switch, engineered for inestimable reliability and robust performance in liquid level detection for tanks and vessels. Enjoy a special rate when you redeem this top-tier switch, which features a micro-switch or proximity sensor option, output flexibility (SPST/SPDT/DPDT), and an explosion-proof design. Constructed with gorgeous SS304/SS316 wetted parts, the switch boasts IP65-IP68 ingress protection and operates in harsh industrial environments. Suitable for water, oils, solvents, and chemicals, its field-adjustable settings and industrial-grade construction ensure dependable automation and precise control across numerous applications-making it an invaluable investment in protection and process management.

Versatile Liquid Level Control

The Displacer Type Level Switch is used for controlling and monitoring liquid levels within tanks and vessels. Designed for demanding application areas such as chemical processing, water treatment, oil refineries, and general industry, it is used as a reliable on/off switch, preventing overflows and ensuring process safety. With multiple mounting options and compatibility with a range of media, this level switch delivers accuracy and endurance across diverse industrial settings.

Certifications, Policies, and Domestic Reach

Each Displacer Type Level Switch is manufactured under strict quality and explosion-proof certifications based on IS/IEC standards, ensuring industry-compliant performance. Our secure shipping logistics guarantee the prompt and safe exchange of units across India's main domestic markets. We offer a sample policy to help you review the product's features firsthand, further backed by responsive support and straightforward exchange options for your business peace of mind.

FAQ's of Displacer Type level Switch:

Q: How does the Displacer Type Level Switch operate?

A: The switch operates through the movement of a displacer, which changes position as the liquid level fluctuates. This motion mechanically or electronically activates the switch, providing instantaneous on/off output for level control.

Q: What applications are best suited for this level switch?

A: It is ideal for liquid level monitoring and control in tanks and vessels used in chemical, water treatment, oil, and general industrial processes, especially where robust and explosion-proof equipment is needed.

Q: When should I choose SPST, SPDT, or DPDT output?

A: Your choice depends on the required control logic and system configuration. SPST is for simple switching, SPDT allows switching between two circuits, while DPDT is used for more complex automation where dual circuits must be controlled.

Q: Where can the Displacer Type Level Switch be installed?

A: It can be mounted on the top or side of tanks using flanged or threaded process connections. BSP threaded ports and alternative options are available to meet specific installation requirements.

Q: What is the process for ordering and receiving this level switch?

A: You can buy the switch directly, and we will arrange secure shipping through our logistics partners. Sample requests and exchanges are supported as per our policy, ensuring you receive the right fit for your application.
